The Origins of Flow Control and Acknowledgements

Erik Meijer recently explained the duality of Enumeration and Observation.1 Subscribing to a feed of items is dual to retrieving an enumerator and going through the items.

Reading his article, I was surprised to realise that there’s a corresponding symmetry between credit-based flow control and message acknowledgement!

Generalising the idea of polling (enumeration) yields flow control, and generalising subscription (observation) yields acknowledgement.

Flow control and Acknowledgement

When designing network protocols such as TCP or AMQP, two problems arise that are both crucial to the robustness and performance of the system being designed:

  • How do we avoid flooding a receiver with messages? and
  • How do we know when a receiver successfully received a message?

The solutions to these problems are flow control and acknowledgements, respectively. The rest of this article will show how these solutions arise from plain old enumeration and observation. I’ll briefly comment on their manifestations in TCP and AMQP toward the end.

Enumeration and Observation

These message sequence diagrams illustrate the use of .NET’s IEnumerator<T> and IObserver<T> as described in Erik’s article. In each diagram, the application is working with some collection containing two values, 11 and 22.

It’s hard to see the symmetry by looking at the diagrams above. The design of .NET’s IEnumerator<T> API is obscuring it by separating MoveNext from Current.

To really see the symmetry properly, we’ll move to a language where we can use algebra to simplify the problem: SML.

SML types for enumeration and observation

The SML type corresponding to IEnumerator<T> might be written as the following (ignoring exceptions, since they aren’t really relevant to the problem at hand): 2

type 'a enumerator = (unit -> bool) * (unit -> 'a)

This is a pair of methods, (MoveNext, Current), corresponding directly to the methods in .NET’s IEnumerator<T> interface. Since it doesn’t make sense to be able to call Current if MoveNext has returned false, by applying a little domain-knowledge and a little algebra we see that this definition is equivalent to the simpler:

type 'a enumerator = unit -> 'a option

We have combined the two methods together, eliminating the possibility of making a mistake. A NONE result from the single combined method indicates that there are no more values available, and a SOME v result carries the next available value v if there is one.

Translating Erik’s almost-mechanically-derived IObserver<T> interface to SML, again ignoring exceptions, and following the 'a option rewrite we used on enumerator, we arrive at:

type 'a observer = 'a option -> unit

The duality is crystal clear at this point. An enumerator has type unit -> 'a option, where an observer has type 'a option -> unit. Enumerators act as senders of information, and Observers act as receivers.

Here’s a message sequence diagram, equivalent to the one above, but using the SML types instead of the .NET interfaces:

Now the symmetry really stands out.

On the left, we can see that when enumerating, an information-free () message indicates that the receiver is ready for the next piece of information from the sender. This is (credit-based) flow control! 3

On the right, we can see that when observing, an information-free () message indicates that the receiver has finished processing the most-recently-sent piece of information from the sender. This is acknowledgement! 4

Enumerators work by the receiver issuing a unit of flow-control credit, and the sender then sending a single value. Observers work by the sender sending a single value, and the receiver then issuing a single acknowledgement message.

Pipelining credit and acknowledgement messages

Let’s take this a step closer to a real network protocol by introducing pipelining of messages. It’s important to be able to reduce latency by decoupling the issuing of a request from the processing of that request. Here we drop the notational distinction between requests and responses, drawing just one kind of arrow for both kinds of message.

All we’ve done here is moved all the “requests” up to the top of each sequence, and all the “responses” to the bottom.

Remember that on the left, () indicates an issue of credit, so that the sender is permitted to send an additional piece of information to the receiver, while on the right, () indicates acceptance of a preceding piece of information by the receiver.

Batching pipelined credit and acknowledgement messages

We can save some bandwidth by applying some of the algebraic tricks we used earlier, looking for a way of compressing those sequences of () messages into informationally equivalent batch credit-issues and acknowledgement messages.

Recall that our enumerator function takes a single () and returns an 'a option, which means either the next available datum or the end of stream:

type 'a enumerator = unit -> 'a option

Switching from SML to abstract type algebra for a moment, let’s model pipelined requests and responses as lists. The algebraic types involved (don’t forget this introduction to type algebra) are

RequestPipeline = 1 + (1     * RequestPipeline)
ReplyPipeline   = 1 + (Value * ReplyPipeline)

These are equivalent to

RequestPipeline = 1 + 1*1   + 1*1*1       + 1*1*1*1           + ...
ReplyPipeline   = 1 + Value + Value*Value + Value*Value*Value + ...

Now, there’s nothing sensible we can do to compress the reply pipeline in the absence of special knowledge about the sequence of values being transferred, but the request pipeline looks very repetitive. It is, in fact, a unary representation of natural numbers. We can use a binary representation instead to save enormous amounts of bandwidth.

Analogous reasoning lets us compress the stream of acknowledgements leaving an observer, so let’s use natural numbers to model our batched credit-issue messages and acknowledgement messages:

Notice how in each case we’ve replaced three separate information-free messages with a single message carrying a natural number, 3. Pipelining and batching credit and acknowledgement messages improves both latency of delivery and usage of available bandwidth.

Analyzing TCP and AMQP

TCP has an elegant flow- and retransmission-control mechanism, the sliding window. Each byte in a TCP stream is separately numbered so that it can be referred to unambiguously. Each TCP segment contains an ACK field that tells a sender which bytes a receiver has seen so far: in other words, the ACK field acknowledges received data. Each segment also contains a Window Size field that tells the sender how much more data it is currently permitted to send: in other words, the amount of credit the receiver is willing to issue.

Looking at things through the lens of the enumerator/observer duality, it’s clear that TCP makes use of both interfaces simultaneously, since it is both issuing flow credit and acknowledging data receipt. There is some generalisation of both interfaces waiting to be exposed! I hope to write more on this in a future article.

Another interesting aspect of TCP is the way that it numbers its FIN segments as part of the transmitted data stream, ensuring reliable 5 notification of stream termination. This corresponds to the acknowledgement of the final NONE in the sequence diagrams above. You might think that the acknowledgement of the end of a stream was optional, but if you omit it, the reliable-delivery characteristics of the protocol change quite substantially: you’re forced to either introduce an out-of-band reliable shutdown subprotocol, or to fairly drastically change the way timeouts are used to decide how long to retain the necessary state.

AMQP also includes something similar to credit-based flow control and message acknowledgements. Flow credit can be arranged by using a Basic.Qos command before transmission begins, and acknowledgement of received messages is done using Basic.Ack commands. However, the protocol combines replenishment of credit with acknowledgement of data: Basic.Ack has a dual role (pardon the pun). Ideally replenishment of flow credit would be done separately from acknowledgement of data, with a command for each task, mirroring the way TCP uses a separate header field for each function.

Besides AMQP’s core subscription system, centred around Basic.Consume, there is a less-commonly-used polling based method of transferring messages, Basic.Get. Basic.Get is very close to being an instance of the simple SML 'a enumerator function type introduced above, and doesn’t include any way of pipelining or batching requests or responses.

Conclusions and future work

The duality between IEnumerator<T> and IObserver<T> extends into a network protocol setting. By looking at it in a network protocol context, we can see the natural emergence of credit-based flow control on the one hand, and acknowledgement on the other. With this model of a data transfer protocol in mind, we can examine existing protocols such as TCP and AMQP to see how they map to the operations we have identified.

There are one or two remaining loose ends I’m interested in following up. Firstly, what is the generalisation of both interfaces, so evident in both TCP and AMQP, like? Whatever it is, it could turn out to be a good candidate for a generalised model of a flow-controlled reliable information stream. Secondly, both IEnumerator<T> and IObserver<T> are inherently stateful approaches to data streaming. What do we see if we switch to pure-functional models of enumeration and observation? What are the analogous network protocol models like? I suspect that the answers here will lead in the direction of more RESTful models of message transmission such as RestMS and ReverseHTTP.

  1. Erik’s article is available as HTML and also as a PDF, which is the form I originally saw it in. Thanks to @hylomorphism for pointing me toward the article and thus kicking off this interesting train of thought.

  2. SML code illustrating the use of these enumerator and observer types can be found here

  3. There are other kinds of flow control besides credit-based: XON/XOFF and RTS/CTS signalling will be familiar to those that have used serial links and modems.

  4. Specifically, transfer of responsibility. The receiver of a message, by sending () to the sender of the message, indicates that it has taken responsibility for the message, and that the sender no longer needs to concern itself with it or attempt further redelivery. There are other kinds of acknowledgement scheme: NAKs, for example, are used in multicast applications to indicate a gap in a received data stream.

  5. I should really put the word “reliable” in scare quotes…
